Cylindrical battery automatic tableting machine

CY-521 Cylindrical battery automatic tableting machine is a special production equipment for the production of lithium ion battery electrode pieces. The whole production process is to hang the cut pole sheet coil on the reel, automatically feed the pole lug, weld the pole lug, paste the protective tape, and finally cut the finished pole sheet automatically according to the set length.

Product characteristics：

1. The frame is welded by steel profiles and aged, the body is made of high-quality steel plates, both sides are grinding, with high flatness and good structural rigidity to ensure running accuracy;

2. Guide roller: aluminum alloy surface superhard oxidation treatment, high surface hardness, not easy to wear;

3. Hardware and wiring are divided into functional blocks, strong current and weak current are separated, with short-circuit overload, leakage and other protection functions;

4. The machine conforms to ergonomics, the touch screen interface layout is reasonable, the parameters are adjustable, the running state can be dynamically displayed, the fault can be dynamically displayed and the information prompt is sent on the touch screen, and the accurate production counting function is available.

purchase information：

If you are interested in our CY-122-M pole ear rotary kneading machine, please contact us for more information and a quote.

Phone：+86 136 6380 8508

Email：jason@cysitech.com

Sales manger：Jason.Zhang

WhatsApp:+86 150 3827 2566

Wechat：cykytech

technical parameters：

 Application case：

Experiment preparation

1. Material preparation: Prepare an appropriate amount of positive electrode material (such as lithium cobaltate), negative electrode material (such as graphite), conductive agent (such as carbon black), binder (such as PVDF) and solvent (such as NMP).

2. Tool preparation: In addition to the Cylindrical battery automatic tableting machine, it is also necessary to prepare electronic scales, stirrers, gloves and other auxiliary tools.

3.Environment preparation: Ensure that the operation area is clean and dust-free, and that the temperature and humidity meet the technical requirements to avoid the impact of static electricity and dust. The operation area should be equipped with a ventilation system to prevent the accumulation of harmful gases.

Experimental procedure

Raw material mixing:

1. Use electronic scale to accurately weigh the required positive electrode material, negative electrode material, conductive agent and binder.

2. Put the measured material into the blender, add the appropriate amount of solvent (such as NMP), start the blender to ensure that the components are evenly mixed to form a uniform slurry.

Slurry coating:

1. Pour the mixed slurry into the hopper of the Cylindrical battery automatic tableting machine.

2. Set the appropriate coating parameters, including coating speed, coating thickness and drying temperature. According to the characteristics of the slurry and the requirements of the electrode sheet, small batch test can be carried out first, adjusted to the best state and then formally put into production.

3. Start the automatic film-making machine, and the slurry is evenly coated on the substrate (such as aluminum foil or copper foil) through the coating device.

Drying treatment:

1. The coated electrode sheet enters the drying device and is dried according to the set temperature and time to ensure that the slurry is fully cured.

2. During the drying process, you can monitor the drying effect through the observation window to ensure that the electrode surface is flat and no bubbles.

Electrode cutting:

1. Take the dried electrode sheet out of the drying device and enter the cutting device.

2. Set proper cutting parameters, including cutting length and width. Ensure that the cut electrodes have the same size and neat edges.

3. Start the cutting procedure, and the cutting device will automatically complete the cutting of the electrode sheet. The cut electrodes are automatically collected into the specified container.

Quality inspection:

1. Carefully check each cut electrode sheet to ensure uniform thickness, smooth surface, no cracks and impurities.

2. Use tools such as microscope and thickness gauge for detailed inspection and record relevant data.

Performance test:

Some samples were randomly selected for electrochemical performance test to evaluate key indicators such as specific capacity and internal resistance of the electrode sheet.

The test results were recorded, and the influence of Cylindrical battery automatic tableting machine on the performance of electrode sheet was analyzed.

Result analysis

By using a fully Cylindrical battery automatic tableting machine, the company achieved the following results in the preparation of electrode sheets for cylindrical lithium batteries:

 Improve production quality: high precision coating system and stable drying device ensure the thickness uniformity and surface flatness of the electrode sheet, reduce cracks and bubbles, and improve the quality of the electrode sheet.

 Enhanced consistency: Standardized operating procedures and high-precision equipment ensure that the size and performance of each electrode sheet are highly consistent, improving the consistency and stability of the battery.

 Improve production efficiency: The automated integrated machine design significantly shortens the production time, improves production efficiency and reduces labor costs.

 Reduce defective product rate: The standardized operation process and high-precision equipment reduce the error caused by human operation and reduce the defective product rate.
