lithium battery slurry High temperature coating machinelithium battery slurry High temperature coating machine

lithium battery slurry High temperature coating machine

     high temperature coating machine is mainly used for mixing and dispersing materials. The barrel body is made of SUS 310S stainless steel material, which is resistant to corrosion and easy to clean

CYKY-VCJ-15 high temperature coating machine is mainly used for mixing and dispersing materials. The barrel body is made of SUS 310S stainless steel material, which is resistant to corrosion and easy to clean. High temperature heating function, so that the material is fully heated, improve the material contact area, make the material coating more uniform, improve product quality. Multiple groups of inclined blades of the cone barrel spindle operate at high speed to fully disperse materials. Dual safety temperature monitoring system stably controls heating plate temperature and monitors material temperature. The equipment has air cooling, water cooling, oil cooling system, effectively prevent internal high temperature overflow, reduce energy consumption loss, extend the service life of the equipment. This equipment has a wide range of uses, such as slurry, powder mixing, dispersion, crushing, drying, granulation and coating functions, this equipment in new energy materials, medicine, coatings and other fields widely used.

Product characteristics:

Multi-layer inclined blade, high speed dispersion, mixed materials;

High temperature heating function, the material is heated evenly, improve product quality and efficiency;

A variety of cooling systems to prevent internal high temperature overflow, reduce energy consumption;

Double safety temperature monitoring system, temperature control, material temperature, real-time monitoring;

SUS 310S stainless steel barrel body, anti-corrosion, easy to clean;

The equipment is simple to operate and has high stability.

Purchase information:

If you are interested in our High temperature coating machine, please contact us for more information and a quote.

Contact number: +8615617875939

E-mail: gordon@zztainuo.com

Contact: Gordon Zhang

Wechat: 15617875939

WhatsApp: +8613592553141

Technical parameters:

Power source

Three-phase five-wire AC380V±10% frequency   50HZ/60HZ±5%

Compressed air source

Interface φ8mm, pressure 0.6Mpa, air consumption: 10m³/hr

Add nitrogen

Interface G1/4 "gas consumption 1.5L/min; 3000mL/min

Ambient temperature range

40%-90%

Relative ambient humidity

10~40

Drive motor

Power

2.2KW

Type

Three-phase asynchronous

Driver

Variable frequency soft start

Cooling mode

Air cooling

Class of protection

IP55

Efficiency class

Lv 3

Heating

Power

9KW

Heating mode

Resistance tape

Cooling water

Pressure range

0.05-0.1Mpa (atmospheric pressure effluent)

Minimum circulation

0.6m³/hr (10 L /min)

Maximum water temperature

5℃±2

Mixing drum body

Barrel material

SUS 310S

Barrel body flange material

SUS 316L

Cone capacity

18L

Effective capacity

610L

Barrel thickness

6mm

Discharge valve diameter

PN10DN100

Mixing blade

Blade material

SUS 316L

Spindle speed

20-165rpm

Blade line speed

Usually used 2 to 3m/s

Blade level

5 floors

Number of blades

5 layers *2 pieces (2 pieces/layer)

Temperature sensor

Sensor type

WRN K

Number of sensors

3pcs

Equipment noise

74 DB

Equipment size

W940mm*D1135mm*H1792mm

Static load

About 730Kg

Dynamic load

About 1100Kg

Main components:

Requirements

Specific specifications

Host

1 set

Application field:

High temperature coating machine is an important processing equipment, its application field is quite wide. Here are some of the main application areas:

 1. Aerospace

In aerospace, aircraft are exposed to extremely high temperatures and extreme environmental conditions during flight. High temperature coating machine can provide effective high temperature resistant coating for aircraft components, so as to protect the aircraft from high temperature environment damage, to ensure its performance and safety.

2. The automotive industry

In the automotive industry, high temperature coating machines also play an important role. It can be used in the coating treatment of automotive engines and exhaust systems to protect these components from high temperatures and corrosive gases. By high temperature coating treatment, the performance and reliability of the vehicle can be improved, and its service life can be extended.

3. The energy sector

In the energy industry, especially in the petroleum and chemical sectors, equipment and pipelines are often exposed to high temperatures and corrosive environments. High temperature coating machines can provide an effective coating for these equipment and pipes, thereby improving their high temperature and corrosion resistance. This helps extend the service life of equipment and pipes and reduces the cost of repair and replacement.

4. Furniture manufacturing industry

The high temperature coating machine can also be used in the furniture manufacturing industry. It can evenly cover decorative paint paper, PVC and solid wood veneer and other materials on the surface of the furniture, improving the beauty and durability of the furniture. This coating treatment not only protects the furniture from scratches and wear, but also increases its water and moisture resistance.

5. Other industries

In addition to the above areas, high temperature coating machines can also be applied to a number of other industries. For example, it can be used for the coating treatment of lines of aluminum-plastic profiles, wood and foam materials, as well as the coating and protection of electronic product housings and internal parts. In addition, it is also widely used in construction, textile, printing and other fields.

In general, high temperature coating machines play an important role in a number of industries with their unique advantages. With the continuous development of science and technology, high temperature coating machines are also constantly upgraded and improved to meet the needs of different industries.
