planetary centrifugal mixer that can be used to mix a wide range of liquid or powder materials. Sample materials can be nano-powders, conductive ceramics, battery powders or slurries, carbon nanotubes, oxide powders and metal powders, etc., which are ideal for laboratory mixing tasks.
The MSK-PCE-V2150 is a two-channel planetary centrifugal mixer that can be used to mix a wide range of liquid or powder materials. Sample materials can be nano-powders, conductive ceramics, battery powders or slurries, carbon nanotubes, oxide powders and metal powders, etc., which are ideal for laboratory mixing tasks.
Planetary centrifugal mixing, rotation and revolution at the same time to homogenize the sample material;
Equipped with temperature sensor, can detect internal temperature change when mixing, overtemperature alarm stop;
The equipment is small in size and can be operated in the glove box;
No contact no stirring blade, minimize pollution;
Mixing, dispersing and defoaming are carried out simultaneously;
Can handle up to two samples simultaneously;
There are two operating modes, automatic and manual, in the automatic mode, different formulation processes can be selected.
If you are interested in our Planetary centrifugal mixer, please contact us for more information and a quote.
Contact number: +8615617875939
E-mail: gordon@zztainuo.com
Contact: Gordon Zhang
Wechat: 15617875939
WhatsApp: +8613592553141
Working power supply | Single-phase AC220V±10%, frequency 50Hz, power 1KW |
Vacuum | Vacuum degree Max-0.085Mpa, customer provides vacuum source or optional vacuum pump (DRV-10 recommended) |
Standard container | Single tank volume 150ml -- effective volume Max.75ml(with double tank) |
Optional container | Single tank volume 30ml -- effective volume Max.15ml(equipped with double tank, tank jig) |
Container material | White HDPE |
Mixture weight | Single can Max.150g |
Velocity of revolution | Stepless speed control (10-2000rpm) Low speed 10-1499rpm, unlimited time High speed 1500-2000rpm a process can run for 7.5 minutes |
Rotational velocity | Velocity of revolution X0.6 |
Balance regulation | The mass should be equal when the two tanks are mixed; When mixing a single can, it is necessary to use another can to adjust the weight to ensure equal quality |
Set time | 1-999 seconds |
Number of time periods | 3-tier |
Formula parameter | 8 groups |
Equipment size | L430*W310*H500mm |
Weight | About 60kg |
Requirements | Specific specifications |
Host | 1 set |
Application field:
The application areas of planetary centrifugal mixers are very wide, according to the search results, the following are some of the main application areas:
1. New energy industry : In the field of new energy, planetary centrifugal mixer is used to mix a variety of battery powder or slurry, such as lithium batteries, solar cells and so on.
2. Electronic and electrical industry : In the electronic and electrical industry, the equipment is used for mixing electronic paste, conductive ceramics and other materials.
3. Chemical raw material industry : The planetary centrifugal mixer is used in the chemical raw material industry to mix a variety of liquid or powder materials, including nano powder, oxide powder and metal powder.
4. Biopharmaceutical industry : In the field of biopharmaceutical, the device can be used to mix pharmaceutical raw materials to prepare uniform drug mixtures.
5. Cosmetics industry : In cosmetics manufacturing, planetary centrifugal mixer is used to mix cosmetic raw materials to ensure product quality and consistency.
6. Food industry : In the food industry, the equipment can be used to mix food raw materials, such as seasonings, additives, etc.
7. Refractory field : In the production of refractory materials, planetary centrifugal mixer can fully mix a variety of refractory materials to ensure the high temperature stability and durability of the product.
8. Artificial stone production : In the production of artificial stone, the equipment also plays a key role, able to mix a variety of raw materials evenly.
9. Solid waste treatment industry : In the solid waste treatment industry, the planetary centrifugal mixer can efficiently mix and treat solid waste materials, so that solid waste materials can be fully utilized, but also made a positive contribution to the cause of environmental protection.
10. Scientific Research and education : In the field of scientific research and education, planetary centrifugal mixer is an indispensable experimental tool in the laboratory, used in various chemical reactions, biological experiments and material preparation and other research processes.
These application areas demonstrate the versatility of the planetary centrifugal mixer and its wide applicability in industrial production and scientific research.
