Planetary vacuum centrifugal mixer is a mixer that can be used to mix all kinds of liquid or powder materials. Sample materials can be nano-powders, conductive ceramics, battery powders or slurries, carbon nanotubes, oxide powders and metal powders. This device is particularly suitable for mixing high viscosity materials.
The CYKY-MZ-8 Planetary vacuum centrifugal mixer is a mixer that can be used to mix all kinds of liquid or powder materials. Sample materials can be nano-powders, conductive ceramics, battery powders or slurries, carbon nanotubes, oxide powders and metal powders. This device is particularly suitable for mixing high viscosity materials.
In addition to rotation + revolution, which can be performed simultaneously by stirring and defoaming/degassing, vacuum reduction function is also added, and nanoscale bubbles can be completely eliminated.
The equipment can provide about 400G of centrifugal force and autobiographical interaction, running smoothly;
Can change the rotation speed, greatly improve the quality after mixing, suitable for a wide range of materials;
The timer can set 9 groups of memory programs, each group of memory programs can remember up to 5 groups of subprograms, can achieve a variety of stirring methods;
If you are interested in our Planetary centrifugal mixer, please contact us for more information and a quote.
Contact number: +8615617875939
E-mail: gordon@zztainuo.com
Contact: Gordon Zhang
Wechat: 15617875939
WhatsApp: +8613592553141
Power supply | Voltage 220VAC±10%, frequency 50Hz, power 1KW(standby 50W) |
Use environment | The recommended ambient temperature is 25±3 ° C, humidity is 38 to 85RH(%), and there is no vibration or electromagnetic interference |
Mixing method | Vacuum + rotation/revolution non-spiral mixing mode |
Continuous running time | 30min |
Maximum agitation | Atmospheric pressure: 250ml, 310g (300ml container); 150ml, 310g (150ml container) Vacuum: 200ml, 310g (300ml container); 120ml, 310g (150ml container) |
Standard container | One 150ml container (DHPE), three 300ml containers (DHPE), and one 150ml container transfer device |
Programmed stirring | The revolution and vacuum degree of 5 programs can be remembered in each operating condition |
Vacuum storage | Rotating unit vacuum storage system |
Vacuum degree | 0.67Kpa (about 5Torr) ~ atmospheric pressure |
Revolution speed | Maximum 2000rpm, resolution 10rpm (stop and 200~2000rpm variable) |
Rotational speed | Max. 1000rpm (1:2 to revolution) |
Safety function | Door lock sensor, positive motion sensor, rotation sensor, panic button |
Equipment size | Self-balancing (no counterweight adjustment required) |
Weight | Can be set up three segments, each segment 200 seconds, a total of 600 seconds (accuracy 1s) |
Requirements | Specific specifications |
Host | 1 set |
Application field:
The planetary centrifugal mixer is an efficient and versatile mixer with a wide range of applications, covering many industrial and scientific fields. The following is a detailed introduction to the application field of the planetary centrifugal mixer:
1. Material science
Nanomaterials: Planetary centrifugal mixers can be used for the mixing of nano-powders, helping to evenly disperse nanomaterials in scientific research and industrial applications.
Conductive ceramics: In the preparation of conductive ceramics, planetary centrifugal mixer can provide efficient mixing effect to ensure the conductive properties of ceramic materials.
Battery material: The mixing of battery powder or slurry is an important part of the battery manufacturing process, and the planetary centrifugal mixer can ensure the uniformity and consistency of the battery material, thereby improving the performance and safety of the battery.
2. Chemical industry
Oxide powder: planetary centrifugal mixer can be used for mixing oxide powder, suitable for the production of catalysts, pigments, coatings and other chemical products.
Metal powder: In the mixing process of metal powder, the planetary centrifugal mixer can provide a uniform mixing effect, which helps the uniform distribution of metal powder in the subsequent processing.
3. Other areas
Laboratory research: The planetary centrifugal mixer has a wide range of applications in the laboratory, and can be used for the mixing of various powders, liquids and other materials to meet the needs of scientific research experiments.
Construction industry: In the construction industry, planetary centrifugal mixer can be used to mix various building materials, such as concrete, mortar, etc., to improve the uniformity and strength of building materials.
Other industrial fields: Planetary centrifugal mixer can also be used for mixing work in glass, refractory, cement products and other industries, helping to improve product quality and production efficiency.
In summary, the planetary centrifugal mixer plays an important role in scientific research and industrial production with its efficient and uniform mixing effect and a wide range of application fields.
