battery extrusion testing machine

battery extrusion testing machine is a device that can be used in the lithium ion battery extrusion testing process. The hydraulic cylinder is selected as the driving element of the equipment, and the special fixture is configured to fix the battery and the working head, which can realize the test of various cylinders, aluminum shells, soft bags and large power cells and battery packs. The equipment design data collection function, the experimental data can be continuously collected and stored. Thoughtful safety design, double-layer sheet metal structure, explosion-proof observation window, back design explosion-proof opening, exhaust gas discharge reservation, can be local and remote control.

Product model: CY-TE904

Installation dimensions: W800mm*D900mm*H2015mm

Weight: About 450Kg

Version number: V1.1

CY-TE904 battery extrusion testing machine is a device that can be used in the lithium ion battery extrusion testing process. The hydraulic cylinder is selected as the driving element of the equipment, and the special fixture is configured to fix the battery and the working head, which can realize the test of various cylinders, aluminum shells, soft bags and large power cells and battery packs. The equipment design data collection function, the experimental data can be continuously collected and stored. Thoughtful safety design, double-layer sheet metal structure, explosion-proof observation window, back design explosion-proof opening, exhaust gas discharge reservation, can be local and remote control。

Feature：

 applicable to GB31241-2014, UN38.3 battery test standard, can be used for battery, battery pack extrusion or needle test;

 According to the standard extrusion function, it can realize arbitrary setting of pressure, deformation and voltage, and automatically set and store test results;
 Extrusion speed, extrusion pressure and other parameters can be set on HMI;
 battery fixture design is convenient and easy to use, can be cylindrical, square, soft pack battery clamping and testing;
 Design the test chamber lighting, explosion-proof outlet device, forced exhaust, test and recharging outlet according to the requirements of use;
 Optional infrared camera monitoring, fire extinguisher, exhaust gas filtration and other function modules;
 Using UL certified components, the equipment runs stably and reliably, with the function of local and remote operation switching;

Parameter：
